Reduced Bore Gate Valve, ASTM A182 F316L, 3/4 Inch, 150 LB

Key Specifications / Features


Model No.VF-231212-FSGV-11

As a distinguished manufacturer of API 602 Reduced Bore Gate Valves, our plant proudly presents a high-performance solution. Specifically designed as a 3/4-inch valve with Class 150 LB rating, DN20 size, and PN20 pressure designation, this forged steel gate valve is crafted from ASTM A182 F316L material. The NO.12 Trim ensures precise flow control for various applications.


Categories: Forged Steel Gate Valves

Tags: 3/4 Inch Gate Valve , ASTM A182 F316L Gate Valve , Class 150 LB Gate Valve , API 602 Gate Valve , DN20 Gate Valve , PN20 Gate Valve , Reduced Bore Gate Valve

Detail Information


Standard: API 602
Material: ASTM A182 F316L
Trim: NO.12
Size: 3/4 Inch
Class Rate: 150 LB
Ends: RF
Operating: Hand Wheel
Wall Thickness: API 602, ASME B16.34.
Face-to-face Dimensions for Flanged Valves: ASME B16.10.
Flange Design: ASME B16.5.
Socket Weld Ends to ASME B16.11.
Screwed Ends (NPT) to ASME B1.20.1.
Butt Welding Ends: ASME B16.25.
Pressure Testing: API 598.

More Body Materials:
ASTM A105, ASTM A182 F304, ASTM A182 F304L, ASTM A182 F316, ASTM A182 F316L, ASTM A350 LF2, ASTM A182 F11, ASTM A182 F22, ASTM A182 F5, ASTM A182 F51, ASTM A182 F321.

Quality Assurance (QA):
Every step from procurement through production, welding, assembly, testing, and packaging is in accordance with quality programs and procedures (ASME Section III manual and ISO 9001 manual).
