ASTM A182 F316 Gate Valve, 1-1/2 Inch, 300 LB, NO.12 Trim

Key Specifications / Features

Model No.VF-231212-FSGV-10

As a leading provider of Forged ASTM A182 F316 Gate Valves, we offer precision-engineered solutions for diverse applications. This 1 1/2-inch gate valve, designed in accordance with API 602 standards, features a NO.12 Trim for enhanced flow control. With a Class 300 LB rating, DN40 size, and PN20 pressure rating, this valve ensures reliable performance in various industrial settings.

Categories: Forged Steel Gate Valves

Tags: ASTM A182 F316 Gate Valve , Class 300 LB Gate Valve , Full Bore Forged Gate Valve , API 602 Gate Valve , RF End Gate Valve

Detail Information

Standard: API 602
Material: ASTM A182 F316
Trim: NO.12
Size: 1 1/2 Inch
Class Rate: 300 LB
Ends: RF
Operating: Hand Wheel
Wall Thickness: API 602, ASME B16.34.
Face-to-face Dimensions for Flanged Valves: ASME B16.10.
Flange Design: ASME B16.5.
Socket Weld Ends to ASME B16.11.
Screwed Ends (NPT) to ASME B1.20.1.
Butt Welding Ends: ASME B16.25.
Pressure Testing: API 598.

More Body Materials:
ASTM A105, ASTM A182 F304, ASTM A182 F304L, ASTM A182 F316, ASTM A182 F316L, ASTM A350 LF2, ASTM A182 F11, ASTM A182 F22, ASTM A182 F5, ASTM A182 F51, ASTM A182 F321.

Quality Assurance (QA):
Every step from procurement through production, welding, assembly, testing, and packaging is in accordance with quality programs and procedures (ASME Section III manual and ISO 9001 manual).
