BS 5352 Gate Valve, Bolted Bonnet, 1/4-2 Inch, 150-800 LB

Key Specifications / Features

Model No.VF-231212-FSGV-01

Discover high-quality bolted bonnet gate valves at our facility, designed to meet international standards such as BS 5352, API 602, and ASME B16.34. Our valves range from 1/4 to 2 inches, accommodating Class 150 to 800 LB applications. Crafted from ASTM A105 material, these valves are available in both full and standard port configurations.

Categories: Forged Steel Gate Valves

Tags: ASTM A105N Gate Valve , API 602 Gate Valve , ASME B16.34 Gate Valve , BS 5352 Gate Valve

Detail Information

BS 5352 Gate Valve, Bolted Bonnet

Design Construction:
API 602, ASME B16.34, BS 5352
Testing according to API 598
Size: 1/4 Inch, 3/8 Inch, 1/2 Inch, 3/4 Inch, 1 Inch, 1-1/4 Inch, 1-1/2 Inch, 2 Inch
      DN6, DN10, DN15, DN20, DN25, DN32, DN40, DN50
Class: 150 LB, 300LB, 400 LB, 600 LB, 800 LB, PN20, PN50, PN63, PN100, PN130
Spiral-wound gasket
Integral backseat
Socket Weld Ends to ASME B16.11
Screwed Ends (NPT) to ASME B1.20.1
Butt Welding Ends to ASME B16.25
Marking MSS SP25
Outside Screw and Yoke (OS & Y)
Self aligning two piece packing gland

More Body Materials:
ASTM A105, ASTM A182 F304, ASTM A182 F304L, ASTM A182 F316, ASTM A182 F316L, ASTM A350 LF2, ASTM A182 F11, ASTM A182 F22, ASTM A182 F5, ASTM A182 F51, ASTM A182 F321.


Ratings:
- carbon steel class 800 1975 psig @ 100°F 138 bar + 38°C
- carbon steel class 1500 3705 psig @ 100°F 255 bar + 38°C
